STEDI Homage 7" LED Headlight - Black (5700K)

DESCRIPTION

A NOD TO THE CLASSIC STYLE.

The stylistic STEDI 7 Inch Homage LED Headlight is a throwback to the classic light design; think of the Jeep CJ, Mercedes G Wagon, Defender, old school muscle cars (to name just a few). A 100% ADR Compliant light that delivers a breaking-edge performance within a retro aesthetic, the STEDI 7 Inch Homage LED Headlight is sure to catch the eye of all car aficionados.

TRAILBLAZING LED TECHNOLOGY.

With a high beam that pushes a staggering 390m @ 1 lux, the STEDI 7 Inch Homage LED Headlight exemplifies the innovation and performance that makes STEDI a leader in the LED automotive auxiliary lighting industry.

390M @ 1 LUX.

Designed with trailblazing dual-mode technology (low and high beam), the STEDI 7 Inch Homage LED Headlight exemplifies the innovation and performance that makes STEDI a leader in the LED automotive auxiliary lighting industry.

LUX GRAPH HIGH BEAM

LUX GRAPH LOW BEAM

BEAM CHARACTERISTICS

GUARANTEED COMPATIBILITY.

The STEDI™ 7 Inch Homage LED Headlight is the ideal upgrade solution for your motorcycle or passenger vehicle that runs factory 7” headlights. The Homage also complies with ADR regulations and is a 100% legal LED headlamp upgrade. Don’t waste time checking whether your vehicle meets the guidelines for retrofitting LED lights; we’ve got you covered from the get-go!



DIMENSIONS

THE NITTY GRITTY.

100% ADR compliant and legal for road use in Right Hand Drive markets.

COMPATIBLE MODELS:

Note: compatible with Positive-Switched Vehicles ONLY (solution for Negatively Switched Vehicles coming soon).

• 1955-1983 Jeep CJ-5
• 1976-1986 Jeep CJ-7
• 1981-1985 Jeep CJ-8
• 1997-2006 Jeep Wrangler (TJ)
• 2007-2018 Jeep Wrangler 2-Door (JK)
• 2007-2018 Jeep Wrangler Unlimited 4-Door (JK)
• Land Rover Defender
• 1982 - 1991 Mitsubishi Pajero (L040)
• GQ Patrol
• Harley Davidson Motorcycles
• Mercedes Benz G Wagon
• Kenworth Trucks with 7 inch round headlight

The above list of compatibility is not exhaustive, please use our vehicle selector above to check fit compatibility.

TECH SPECS

LED	2 x 12W Osram KW H4L531.TE
RAW LUMENS	2400Lm
AMP DRAW	1A@24V 2A@12V
LIFESPAN	30,000 Hours
INGRESS PROTECTION	IP68
OPERATING TEMPERATURE	-40°C~+60°C
LENS MATERIAL	Hardened Polycarbonate Lens
COLOUR TEMP	5700K
VOLTAGE COMPATIBILITY	DC 10V - 28V
PEAK BEAM DISTANCE @ 1 LUX	High Beam: 390m Low Beam: 212m
WEIGHT (each)	0.95kg each
DROP IN REPLACEMENT	#6014, 6015, 6016, H6024 and Par 56 headlamp designs
ADR COMPLIANCE	E922432 E922327
CERTIFICATION	CISPR25 Class 3

WHAT'S IN THE BOX

• 1 x STEDI 7" Homage LED Headlight
